SpaceraiL LEVEL 1 - Connect Rails D, E, F, C

Spacerails, LLC. All rights reserved. Spacerails.com Page 11
STEP 7
(D Rail)
STEP 8
(E Rail)
STEP 9
(F Rail)
STEP 10
(C Rail)
CONNECT RAILS D, E, F, AND C
Use the following illustrations and pictures as references for attaching the Rails to the structure:
Step 7: Connect both D Rail sections to the corner of Shaft B and the back section of the Split.
Step 8: Connect both E Rail sections between the back corner of Shaft D and the back bottom corner of Shaft E.
Step 9: Connect both F Rail sections between the front corner of Shaft C and the front bottom corner of Shaft E.
Step 10: Connect both C Rail sections between the front corner of Shaft D and the middle entrance of the elevator.
A
B
C
D
E
STEP 7
(D Rail)
STEP 9
(F Rail)
STEP 10
(C Rail)
STEP 8
(E Rail)
E
B
C
D
D
