E
2
1
2
Step 1: Interlock Base block tabs
as shown below.
Step 2: Press Base Holder A and
Base Holder B pieces into the Base
blocks for a more secure hold.
SHAFT ASSEMBLY
NOTE:
Illustration of Shafts are 1:2.3 or (approximately 43%) of scale.
A B C D E
63 mm
264 mm
204 mm
261 mm
194 mm
47 mm
159 mm
238 mm
129 mm
101 mm
240 mm
199 mm
D
BASE ASSEMBLY
