Page 8 Seaich Corporation, LLC. All rights reserved. www.seaich.com
|
Spacerails, LLC. www.spacerails.com
Shaft V and Shaft W are
suspended above the base
using Arm B connections
from shafts Q, R, S, and T.
SHAFT ASSEMBLY CONTINUED
Shaft R
Shaft S
Shaft T
Shaft V
Shaft W
60 82 102 144 195 232 337
43 72 101 131 156 183
47 75 104 134 159 186
391
200
200
33 83 124 177 197 227
65 83 107 158 188 228
300
300
TOP
BASE
BACK
OF BASE
FRONT
OF BASE
SHAFT TO BASE ORIENTATION
To Next Page
