CUT RAIL TO SIZE
RAIL PLACEMENT
S
O
Step 1: Measure each section and mark the
cutting point with a pen. Rail measurements
are in Centimeters. Measure by a ruler or tape
measure, or see the included insert for full size
drawings of the rail measurements.
Step 2: Cut each section at a 90° angle to the
correct length.
Use these informational
elements to understand how
to best install the rail to its
proper placement on the
following pages.
E -1
Rail
Rail point to
attach arm
Shaft
letter
Shaft placement
on the base
Arm number
NOTE:
To avoid do-overs and using too much
rail, cut generously (slightly longer than
required) to begin with. You can always cut
a long rail shorter.
1150 cm
a
450 cm
b
100 cm
c
100 cm
d
