C
BASE ASSEMBLY
F K
G L
O
P
D I
E J
Base Level 1:
13 - Bases
9 - Small Base
Holders
6 - Big Base
Holders
Base Level 2:
1 - Double Base
Indicated by:
Base Level 2 will
attach atop of the
200mm shafts: F, K,
O, P, G, L, P, R
Base Level 3:
1 - Double Base
Indicated by:
Base Level 3 will
attach atop of the
base level 2, 200mm
shafts: D, E, I & J.
Assemble base components as shown
in the following congurations.
