MOVING SYSTEM
HEIGHT
ADJUSTMENT
1. While holding pole, rotate basketball sytem
forward until wheels engage with ground.
2. Move basketball system to desired location.
3. Carefully rotate basketball system upright.
4. Check system for stability.
B
A
Rotate crank
handle to raise
a
nd lower
backboard.
Do not over crank
handle beyond the
manufactured height
i
ndicator range of
7-1/2 - 10 feet.
Damage may be
c
aused to the screw
jack’s internal
adjustment
mechanism if
adjusted over 10 or
under 7-1/2 feet.
33
Owner must ensure that all players know and follow these rules
for safe operation of the system.
WARNING
DO NOT HANG on the rim or any part of the system including
backboard, support braces or net.
During play, especially when performing dunk type activities,
keep player's face away from the backboard, rim and net.
Serious injury could occur if teeth/face come in contact with
backboard, rim or net.
Do not slide, climb, shake or play on base and/or pole.
After assembly is complete, fill system completely with water
or sand and stake to the ground. Never leave system in an
upright position without filling base with weight, as system
may tip over causing injuries.
When adjusting height or moving system, keep hands and
fingers away from moving parts.
Do not allow children to move or adjust system.
During play, do not wear jewelry (rings, watches, necklaces,
etc.). Objects may entangle in net.
Surface beneath the base must be smooth and free of gravel or
other sharp objects. Punctures cause leakage and could cause
system to tip over.
Keep organic material away from pole base. Grass, litter, etc.
could cause corrosion and/or deterioration.
Check pole system for signs of corrosion (rust, pitting, chipping)
and repaint with exterior enamel paint. If rust has penetrated
through the steel anywhere, replace pole immediately.
Check system before each use for proper ballast, loose
hardware, excessive wear and signs corrosion and repair
before use.
Check system before each use for instability.
Do not use system during windy and/or severe weather
conditions; system may tip over. Place system in the storage
position and/or in an area protected from the wind and free
from personal property and/or overhead wires.
Never play on damaged equipment.
See instruction manual for proper installation and
maintenance.
When moving system, use caution to keep mechanism from
shifting.
Keep pole top covered with cap at all times.
Do not allow water in tank to freeze. During sub-freezing
weather add 2 gallons of non-toxic antifreeze, sand or empty
tank completely and store. (Do not use salt.)
While moving system, do not allow anyone to stand or sit on
base or have added ballasting on base.
Do not leave system unsupervised or play on system when
wheels are engaged for moving.
Use Caution when moving system across uneven surfaces.
System may tip over.
Use extreme caution if placing system on sloped surface.
System may tip over more easily.
Read and understand warnings listed below
before using this product.
Failure to follow these warnings may result in
serious injury and/or property damage.
ID#: 55679001 02/12
In the U.S.: 1-800-558-5234
In the U.S.: 1-800-558-5234
In Canada: 1-800-284-8339
In the U.S.: 1-800-334-9111
In the U.S.: 1-800-558-5234
In Canada: 1-800-284-8339
In Aus tral ia: 1-30 0-36 7-58 2
Trademarks registered
in the USA and other countries.
NOTICE TO ASSEMBLERS
Adult Assembly Required. Dispose of ALL packaging materials promptly. As with all products, periodically
inspect for loose small parts.
Assembled unit MUST be filled with sand or water at ALL times.
ALL basketball systems, including those used for DISPLAYS, MUST be assembled and installed according
to instructions. Failure to follow instructions could result in SERIOUS INJURY. It is NOT acceptable to
devise a makeshift support system.
