SPALDING E6A994 - Page 23

23
BOARD PAD - PARTS LIST - KIT #4
Item Qty. Part No. Description
14 4 203100 Hex Flange Nut 5/16-18
44 4 208892 Bolt, Hex Flange, 5/16-18 x 1.625 Long
53 1 900033 Bracket, Slam Jam
54 1 206048 Bolt, Tee 3/8-16, 3.25” Long
59 1 20157801 Board Pad, Left Section
60 1 20157901 Board Pad, Right Section
61 1 201580 Board Pad, Center Section
62 2 201596 Screw, 1/4 x 1.25
63 6 206303 Washer, Flat, 1/4
65 4 202871 Screw, 1/4 x .75
201596 Screw 1/4 x 1.
#62 (2)
#63 (6)
BOARD PAD - HARDWARE IDENTIFIER - KIT #4 Shown Full Scale
20157801
#59 (1)
20157901
#60 (1)
#61 (1)
KIT #4
202871 - SCREW HEX WASHR HD TAP SLOTTED 1/4 X 3/4
#65 (4)
#54 (1)
#44 (4)
#53 (1)
Not Shown Full Scale
203100
NUT, HEX FLANGE, 5/16-18
#14 (4)
