SPALDING E6A994 - Outside View

37
Apply Height Adjustment and Moving Label (46) to front of pole, where it is clearly visible.
26.
27.
Install net (43).
EXACTA-HEIGHT : ADJUSTMENT
PORTABLE
511679
Size = 4" x 5.5"
Corner Radius = 3/8"
Die Cut Label
3.25 Mil Vinyl
All Temp. Permanent Adhesive
1 Mil. Polypropolyne Overlaminate
Illustrator 8.0 = EPS
Backing + 1/16 Circumference
Rolls of 500
2
2
1
3
TO ADJUST BACKBOARD:
1. While holding handle, remove pin.
2. Move elevator up or down to
desired height.
3. Replace pin full length to lock
system at desired height.
511679 05/05
1
2
4
3
MOVING SYSTEM
Adjust basketball backboard
height to lowest position.
While holding pole, rotate
basketball system forward
until wheels engage with
ground.
Move basketball system to
desired location.
Carefully rotate basketball
system upright.
1.
2.
3.
4.
5.
Check system for stability.
HEIGHT ADJUSTMENT
46
OUTSIDE VIEW
34
34
B.
43
D.
C.
43
A.
