6
PARTS LIST (ALL) - See Hardware Identifier
NOTE
Hardware kit is designed for more
than one style of basketball system.
Not all hardware will be used.
Item Qty. Part No. Description
1 1 600335 Base
2 2 908184 Strut, Pole to Base, Black
3 1 701292 Exacta Height Assembly, Black
4 1 FR908006 Top Pole Section, Black
5 1 901403 Middle Pole Section, Black
6 1 FR908181 Bottom Pole Section, Black
7 2 108183 Wheel Bracket
8 2 266200 Wheel, 4 Inch
9 2 10818201 Rod, Axle
10 1 203099 Nut, Ny-lock, 5/16-18
11 4 203063 Nylon Insert Lock Nut, 3/8-16
12 1 202662 Bolt, Hex Head, 5/16-18 x 4-1/2 Long
13 4 207550 Pushnut, 7/16 Shaft Diameter
14 13 203100 Hex Flange Nut 5/16-18
15 1 801100 Bracket, Pole Mount
16 2 203053 Carriage Bolt, 5/16-18 x 4 Long
17 4 203232 Washer, Flat, 3/4” O.D.
18 2 204962 Bolt, Hex Head, 5/16-18 x .625 Long
19 2 206360 Bolt, Hex Head, 3/8-16 x 2-5/8 Long
20 2 600282 Spacer, Plastic Biscuit
21 2 204857 Spacer, Metal 1/2” O.D. x 1.44 Long
22 2 204859 Cover, Pin Slide
23 1 203038 Carriage Bolt, 5/16-18 x 2-3/4 Long
24 1 204850 Pin, Locking
25 1 204853 Lanyard, Black Coil
26 4 208891 Spacer, .380 I.D. x .67 Long
27 2 208890 Bolt, Hex Head, 3/8-16 x 5.625 Long
28 1 600337N Cover, Front
29 4 206244 Bolt, Hex Head, 1/2-13 x 8 Long
30 4 201642 Spacer, Plastic, .530 I.D. x .625 Long
31 5 206340 Lock Nut, Hex 1/2-13
32 2 901402 Elevator Tube, Lower - Long, Black
33 1 204838 Spring, Counter Balance
Item Qty. Part No. Description
34 1 Rim
35 2 901401 Elevator Tube, Upper - Short, Black
36 2 201682 Spacer, .530 I.D. x 1.875
37 2 900867 Plate, Triangle, Black
38 1 600137 Cap, Pole Top
39 2 200520 Screw, #8 x 3/4 Long
40 1 202605 Bolt, Hex, 1/2-13 x 4.25 Long
41 1 203617 Cap, Base
42 1 206990 Reinforcement Bracket
43 1 Net
44 4 208892 Bolt, Hex Flange, 5/16-18 x 1.625 Long
45 2 203156 Bolt, Hex Head, 5/16-18 x 1” Long
46 1 511679 Label, Height Adjustment and Moving
FR511679 Label, Height Adjustment and Moving,
French
47 6 208505 Carriage Bolt, 5/16-18 x 1.5 Long
48 1 206089 Spacer, Plastic, .530 I.D. x 3.5 Long
49 1 108181 Plate, Pole Mounting
50 2 203679 Bolt, Hex Head, 3/8-16 x 2 Long
51 6 203218 Washer, Flat, 5/16
52 1 200516 Cover, Bolt End, Vinyl
53 1 900033 Bracket, Slam Jam
54 1 206048 Bolt, Tee, 3/8-16, 3.25” Long
55 1 200318 Bracket, Reinforcement, Slam Jam
56 1 208760 Spring, Rim
57 1 203795 Nut, Special, 3/8-16
58 1 203470 Washer, Flat, 1.5 O.D.
59 1 20157801 Board Pad, Left Section
60 1 20157901 Board Pad, Right Section
61 1 201580 Board Pad, Center Section
62 2 201596 Screw, 1/4 x 1.25
63 6 206303 Washer, Flat, 1/4
64 1 200503 Cover, Black OR
200504 Cover, Red
65 4 202871 Screw, 1/4 x .75
66 1 220579 Spacer, Metal, 0.51 ID x 5.0 Long
To Next Page
