Guidance and manufacturer’s declaration – electromagnetic emissions
The 3400 is intended for use in the electromagnetic environment specified below. The customer or the user of the 3400 should assure
that it is used in such an environment.
Emissions test Compliance Electromagnetic environment – guidance
RF emissions
CISPR 11
Group 1
The 3400 uses RF energy only for its internal function.
Therefore, its RF emissions are very low and are not likely to
cause any interference in nearby electronic equipment.
RF emissions
CISPR 11
Class B The 3400 is suitable for use in all establishments, including
domestic establishments and those directly connected to the
public low-voltage power supply network that supplies
buildings used for domestic purposes.
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
Harmonic emissions
IEC 61000-3-2
Class A
Voltage fluctuations/
flicker emissions
IEC 61000-3-3
Complies
Guidance and manufacturer’s declaration – electromagnetic immunity
The 3400 is intended for use in the electromagnetic environment specified below. The customer or the user of the 3400 should assure that it is used in such
an environment.
Immunity test IEC 60601
test level
Compliance level Electromagnetic environment – guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
6 kV contact
8 kV air
6 kV contact
8 kV air
Floors should be wood, concrete or ceramic tile. If floors are covered
with synthetic material, the relative humidity should be at least 30 %.
Electrical fast
transient/burst
2 kV for power
supply lines
2 kV for power
supply lines
Mains power quality should be that of a typical commercial or hospital
environment.
IEC 61000-4-4
1 kV for input/output 1 kV for input/output
lines lines
Surge
IEC 61000-4-5
1 kV line(s) to line(s)
2 kV line(s) to earth
1 kV line(s) to line(s)
2 kV line(s) to earth
Mains power quality should be that of a typical commercial or hospital
environment.
interruptions and <5 % UT <5 % UT Mains power quality should be that of a typical commercial or hospital
voltage variations
on power supply
input lines
(>95 % dip in UT)
for 0,5 cycle
(>95 % dip in UT)
for 0,5 cycle
environment. If the user of the3400 requires continued operation during
power mains interruptions, it is recommended that the 3400 be
powered from an uninterruptible power supply or a battery.
40 % UT
40 % UT
IEC 61000-4-11 (60 % dip in UT) (60 % dip in UT)
for 5 cycles
for 5 cycles
70 % UT 70 % UT
(30 % dip in UT) (30 % dip in UT)
for 25 cycles
for 25 cycles
<5 % UT <5 % UT
(>95 % dip in UT) (>95 % dip in UT)
fo
5 sec fo
5 sec
Power frequency
(50/60 Hz)
magnetic field
IEC 61000-4-8
3 A/m
3 A/m
Power frequency magnetic fields should be at levels characteristic of a
typical location in a typical commercial or hospital environment.
NOTE UT is the a.c. mains voltage prior to application of the test level.
