10
ATTACHMENTS
NOTE: Attachment Hub is optional.
The ranges of attachments that can be operated from the Attachment
Hub are listed below. When using an attachment, lubricate the Drive Stud
(D) using a food quality grease or oil. To fix to the mixer refer to Figure 4.
Release the Thumbscrew (G) and slide the shaft of the attachment into the
hub ensuring that the Drive Stud (D) engages in the socket within the hub.
Rotate the attachment to line up the Location Peg (E) with its mating hole in
the hub and push firmly home. Tighten thumbscrew to secure.
CAUTION: Only fit attachments when the mixer is stationary and never when it is
operating. Do not use attachments when mixing.
The recommended speed range for some of the attachments available is shown in table below.
Recommended speed
1
st
gear 2
nd
gear 3
rd
gear
V99S Veg. Prep.
VH-12 Mincer
Vegetable Preparation With a
range of 8 plates to slice, grate
or shred all types of vegetable
and fruit from nuts and
cabbage to carrots and cheese.
A no.12 mincing attachment which
works wonders with meat, fish and
vegetables alike.
NOTE: Make sure the bowl is up and the bowl guard is closed, otherwise the mixer will not function.
NOTE: If you still don’t understand or have any doubt of operation, please don’t use the machine and
contact the local representative.
Operating Instructions
