2
A)
Bowl
B) Removable Bowl Guard
C) Planetary Shaft
D) Attachment Hub*
E) Control Panel
F) Gear Lever
G) Additions Chute
H) Bowl Lift Handle
(Wheel)
I) Bowl Cradle
NOTE: Attachment Hub is optional.
Control Panel
A) Emergency Stop
B) Start
C) Timer**
NOTE: Timer is optional on Model SP-100A, SP-100A/nh,
SP-200A and SP-200A/nh.
D) Bowl Raise Button
E) Bowl Lower Button
(Available for SP-A80HI and
SP-A80I Only)
NOTE: Oil Meter Indicator is only available for SP-A80HI, SP-A80I, SP-B80HI and SP-B80I.
INSTALLATION
- The machine is supplied factory lubricated and ready to run. It should be positioned on any solid,
level and non-skid work surface that is nonflammable. Install in work area with adequate light and
space.
- For Smaller Capacity Model, you may place the mixer on bench which
is capable of supporting a load of mixer’s weight. For safety, the mixer
Installation Instructions
