USER’S MANUAL
EN
10
Ambient air free from abnormal amounts of dust, acids,
corrosive substances etc. other than those
generated by the welding process
Base of the welding power source inclined no more than 10°
Range of ambient air temperature
during storage and transport
-20°C to +55°C
Duty cycle (def.)
Duty cycle is the time during which You can weld or cut at a certain load without causing overload.
Itis expressed in percent for period of complete cycle which equals 10 minutes. For example: 60% duty
cycle means that for 6 minutes device can operate at given load, after that required 4 minutes time
break (no-load operation). Duty cycle is given to ambient temperature of 40°C.
Protection against overheating (def.)
Security system from overheating will turn on when the device is over-heat (possibility of work
isturned off, abnormal indicator on front panel lights up). In such a situation, You should not turning
off the unit immediately. Wait some time until fan cools the unit. Time to return to the state from
overheating can take up to approx. 15 minutes.
The device has a degree of protection IP23. Which means that it is intended to be used in closed and
covered areas and suitable for use outdoors. However it is not designed to be used outdoor during
precipitation if it is not covered.
6.2 TECHNICAL PARAMETERS
EasyCUT 40E
EasyCUT 40E
Compressor
Input ~1 × 230V ± 10% 50/60 Hz
Cutting current [A] 20 – 40
Max. cutting thickness [mm] 25
Duty cycle [%] 60
PLASMA PARAMETERS
Output working voltage [V] 88 – 96
Recomended work pressure [bar] 5.0 4.5
Recomended compressor efficiency [l/min]
150
Post-gas
✓
Contactless pilot arc ignition (no HF)
✓
OTHER PARAMETERS
Current consumpiton [A] 32
Power factor (cosφ) 0.7
Efficiency η [%] 85
Insulation class H
Protection class IP23
Weight [kg] 8.5 19.5
Dimensions [mm] 460 × 146 × 290 590 × 225 × 410
