SETUP 11
SETUP
ASSEMBLING THE SHARPENER
To watch the How-To video, visit sparxhockey.com/assembly.
1 INSTALL THE CLAMP LEVER
Slide the Clamp Lever (A) onto the Lever Dock (B). Press the
lever down until it clicks into place. When the Clamp Lever is
engaged, it will lay at a slight angle.
2 REMOVE THE TRAVEL GUARD
Open the Skate Clamp by pressing and holding down the
Clamp Lever. Remove the Travel Guard. Release the Clamp Lever.
A
B
1
2
3 REMOVE THE TRAVEL SCREW
Remove the Travel Screw (A) by turning counter-clockwise until
loose.
4 STORING THE TRAVEL SCREW
Install the Travel Screw into the storage location on the Travel
Guard (A) by turning clockwise until hand-tight. Do not
over-tighten.
A
Transporting or moving the Sharpener without the
Travel Guard & Travel Screw installed voids your
Warranty and/or Extended Service Plan. Always
remove the Travel Guard & Travel Screw before
operating the Sparx Sharpener.
