WHIRPOOL JET INSTALLATION
PURE JET INSTALLATION
Electric Motor
Ring
Housing
Jet Cover
Steel Clip
Ring Seal
Housing Rubber Seal
Glass Bowl
Slot (4)
Lips (4)
NOTE: To avoid water leakage, it is
essential to align lips from electric
motor perfectly with slots on housing.
2. When installing motor, first apply
moderate pressure to motor to engage
motor lips (4) with housing slots (4), then
twist motor counterclockwise until
secured.
14 | User Manual Spatech
