NOTE: If the Massage Chair is not provided, then the end-user will need to install a UL listed and
cUL certified massage chair with a suitable Class 2 Power Supply.
TOP MASSAGE CHAIR BASIC INSTALLATION INSTRUCTIONS:
Drill 4 mounting holes ½”.Width=16.5”.
Length=11. Install seat frame and secure
4 screws from bottom base. Using the
provided stand-off to adjust the height of
seat frame as needed to allow seat frame to
travel freely. ssage Chair is not provided,
then the end-user will need to install a UL
listed and cUL/CSA certified massage chair
with a suitable Class 2 Power Supply.
Lift up back massage to engage locking
device. (Manually adjust actuator rod to
lock as needed) Install back cushions.
Plug AC cord to power strip Located
inside of the tub base.
Install seat cushion with 2 screw-Knobs
Lever the back massage and secure 2
hinge screws onto the metal brackets.(Do
not turn the screws all the way in ) Leave
1/4” thread screw head for sliding Install
back shell with 4 screws as Fig.3
16 | User Manual Spatech
