3. PRODUCT INSTALLATION
Install the battery before using the vacuum.
1. Connect the end of the battery to the smart robot vacuum cleaner. Then, push the battery down until
it is inserted in the space designed for it.
2. Place the charging base on a smooth surface on the oor against the wall. Clean the dust and
remove any objects from the area, stick the charging based to the oor. Then, insert the adaptor into
the mains outlet.
TIPS
Insert it into the smart robot
during installation.
Pull it out in the opposite
direction to remove.
CHARGING BASE
PLUG ADAPTOR
1M
1M
3M
Danger! Electrical shock
