7
SpeakerCraft – 1-800-472-5555 – 1-707-778-5733
16 CHANNEL, FULLY CONFIGURABLE POWER AMPLIFIERS
SYSTEM DESIGN BASICS
As shown in Figure 1, a distributed audio/video system is dened by the number
of listening zones it has. Within a listening zone you can listen to only one
source (e.g. CD, Radio, iPod, etc.) at any one time. A listening zone can consist
of a single room or a group of rooms. To achieve different volumes and greater
convenience in different rooms within a zone, individual volume controls can be
used. SpeakerCraft makes volume controls in various styles and colors. When
designing your system, take into account who will use the system and when
they will use it. Consult your local SpeakerCraft dealer for more information.
Family Room
Living Room
RECEIVER RECEIVER
Figure 1
Cable
Box
CD
Player
Blu-ray
Player
Plasma/
LCD
Listening Zone 1
To Next Page
