15
SpeakerCraft – 1-800-472-5555 – 1-707-778-5733
2 Channel, BridgeaBle Power amPlifiers
INSTALLATION
LINE LEvEL AUdIO INpUT
CAUTION! The amplier must be off whenever you make changes
to the input connections.
CASCAdE AUdIO OUTpUTS
The “Cascade Audio Outputs” enable you to connect another amplier to your
preamplier output. The connectors are gold-plated RCA phono jacks. Connect
them to another amplier’s inputs with a standard audio patch cable. The
outputs are not buffered; if you wish to daisy-chain more than 5 SpeakerCraft
2-Channel Amplier ampliers you will need a buffered distribution amplier.
STEP DESCRIPTION
1. Label all of the interconnecting cables
for the sources they connect to.
Use audio patch cables with RCA
phono plugs attached to the ends.
2. Connect the sources by inserting the
RCA plugs into the amplifier’s jacks.
Connect outputs from your sources
to inputs on the amplifier. Never
connect a source or preamplifier’s
input (e.g., record inputs) to
the inputs of your SpeakerCraft
2-Channel Amplifier.
