Spear & Jackson PW2000 - Box Content; Parts List; Assembly; Assemble Gun Holster and Cord Bracket

8 9AFTER SALES SUPPORT 01904 727505 www.spearandjackson-power.com www.spearandjackson-power.com AFTER SALES SUPPORT 01904 727505
WARNING - Pull out the power plug before carrying out
any work on the equipment, and use only original parts.
Before starting any cleaning task, it is important to
inspect the area for objects that could create a hazard.
Remove any objects from the work area that could be
tripped over, such as toys or outdoor furniture. Ensure
that all doors and windows are closed tightly.
BOX CONTENT ASSEMBLY
Detergent bottle x 1
High pressure washer x 1
Gun holster x 1
Crank x 1
High pressure hose x 1
Patio cleaner x 1
Extension lance x 1
Fixed brush x 1
Turbo lance x 1
Adjustable spray lance x 1
Spray gun x 1
Cord bracket x 1
Nozzle pin x 1
Operating manual x 1
Water inlet adapter x 1
Screws x 2
Assemble Gun holster (3) and cord bracket (12).
Connect the hose and spray gun.
Screw the high pressure hose (5) firmly onto the
spray gun (11).
Fit the lance to spray gun.
Insert the adjustable spray lance (10) or turbo
lance (9) to spray gun (11), and twist 1/4 turn to
lock in position.
1 9
2 10
3 11
4 12
5 13
6 14
7
8
15
1
2
3
PARTS
If there are any parts missing, please call the customer helpline on 01904 727505
