FRAME SIZE 44 49 52 54 56 58 61
A STACK (mm)
519 536 552 569 590 610 643
B REACH (mm)
356 359 364 370 378 386 392
C HEAD TUBE LENGTH (mm)
110 125 140 155 175 195 230
D HEAD TUBE ANGLE (°)
69.5 70.5 71 72 72.5 73 73
E BOTTOM BRACKET HEIGHT (mm)
273 273 273 274 274 275.5 275.5
F BOTTOM BRACKET DROP (mm)
77 77 77 76 76 74.5 74.5
G TRAIL (mm)
81 74 71 64 61 58 58
H FORK LENGTH (FULL) (mm)
378 378 378 378 378 378 378
I FORK RAKE/OFFSET (mm)
47 47 47 47 47 47 47
J FRONT CENTER (mm)
576 577 583 585 594 603 619
K CHAINSTAY LENGTH (mm)
420 420 425 425 425 425 425
L WHEELBASE (mm)
984 984 995 998 1008 1017 1033
M TOP TUBE LENGTH (mm)
493 500 530 541 556 569 586
N STANDOVER HEIGHT (mm)
715 739 761 781 801 821 852
O SEAT TUBE LENGTH (mm)
430 460 490 510 530 550 580
P SEAT TUBE ANGLE (°)
75.25 75.25 73.25 73.25 73.25 73.25 73.25
