6.1. Specifications
LOCATION / ITEM QTY DIMENSIONS TOOL
TORQUE
Nm in-lbf
A Main pivot spacers 2 12.1 ID x 19.5 OD x3 W N/A - -
B Main pivot bearings – 6901-2RS (full complement) 2 12 ID x 24 OD x 6 W N/A - -
C Main pivot axle 1 M12 x 81 L 5 mm hex 10 89
D
Main pivot bolt 1 M8 x 12.2 L 5 mm hex 10 89
E
Link bearings 4 8 mm ID X 16 mm OD X 5 mm W N/A - -
F
Top hat spacers 4 6 ID x 8 OD x 9 L N/A - -
G
Link 1 LINK, EPIC WC, MTB, 29, ST, BEARING, CNC N/A - -
H
Link center spacer 2 8.2 ID x 10 OD x 11.6 L N/A - -
I Seatstay bridge 1 MTB, 29, ALY N/A - -
J Lower link bolt and washer 1 M6 x 35 L 4 mm hex 7 62
K Upper link bolt 1 M6 x 40 L 5 mm hex 7 62
L
Upper link nut 1 M6 x 1 N/A - -
M
Seatstay holes 4 N/A N/A - -
N
Seatstay bridge bolts and washers 4 M5 x 21 L 4 mm hex 5 44
O Shock 1 N/A N/A - -
P Rear shock mounting bolt and washer 1 M 6 x 35 L 4 mm hex 7 62
Q Forward shock mounting bolt 1 M6 x 40 L 5 mm hex 7 62
R ICR boot 1 N/A N/A - -
S
Nylon tubes 2 N/A N/A - -
