Specialized FSRXC - FSRxc Frame Geometry

10
* TT length is the Horizontal Measurement from the center-line of the HT at the top of the HT to the center-line of the projected seat tube.
** Stand Over height is measured vertically at the centerpoint of the TT measurement.
FSRxc FRAME GEOMETRY
Headset:
1 1/8”
Seatpost diameter:
30.9mm
Front derailleur clamp:
34.9mm
Seat Collar:
34.9mm
FSRxc Geometry
Women’s FSRxc Geometry
*Top Tube Length
**Standover Hgt
Head Tube Length
Head Tube Angle
Seat Tube Angle
BB Height
Wheelbase
Chainstay Length
1
2
3
4
5
6
7
8
Men’s X-Large
638m
761mm
150mm
70.5
º
73
º
325mm
1128mm
424mm
(25.12”)
(29.96”)
(5.91”)
(12.80”)
(44.41”)
(16.70”)
Men’s Large
612mm
753mm
120mm
70.5
º
73
º
325mm
1100mm
424mm
(24.10”)
(29.65”)
(4.72”)
(12.80”)
(43.31”)
(16.70”)
Men’s Medium
587mm
740mm
110mm
70.5
º
73
º
325mm
1075mm
424mm
(23.10”)
(29.13”)
(4.33”)
(12.80”)
(42.32”)
(16.70”)
Men’s Small
551mm
732mm
100mm
70.5
º
73
º
325mm
1038mm
424mm
(21.70“)
(28.82”)
(3.94”)
(12.80”)
(40.87”)
(16.70”)
*Top Tube Length
**Standover Hgt
Head Tube Length
Head Tube Angle
Seat Tube Angle
BB Height
Wheelbase
Chainstay Length
1
2
3
4
5
6
7
8
Women’s Small
535mm
730mm
100mm
70.5
º
73
º
325mm
1022mm
424mm
(21.06”)
(28.74”)
(3.94”)
(12.80”)
(40.24”)
(16.70”)
Women’s Medium
560mm
732mm
110mm
70.5
º
73
º
325mm
1047mm
424mm
(22.05”)
(28.82”)
(4.33”)
(12.80”)
(41.22”)
(16.70”)
Women’s Large
595mm
753mm
120mm
70.5
º
73
º
325mm
1083mm
424mm
(23.43”)
(29.65”)
(4.72”)
(12.80”)
(42.64”)
(16.70”)
Rear hub spacing:
135mm
BB shell:
68mm
Shock Stroke:
38.1mm (1.5”)
Eye to Eye:
165.1mm (6.5”)
