Specialized TERO EQ KIT - Remove Motor Blind Plugs; Connect Front Light Cable

6
A
B
Rear light
Front light
REMOVE THE MOTOR BLIND PLUGS
Fig. 10
 Remove the blind plugs from the rear and front light
ports on the motor.
CONNECT THE FRONT LIGHT CABLE
Fig. 11
 Using a T10 Torx key, loosen but do not remove the
drive-side ICR port cover (A)
 Remove the cover and guide (B) from the frame.
INFO: To insert the cable connector
through the port cover, you will need to
remove the tab from the port cover (11 B).
 Guide the light cable through the cover and the slot in
the front of the ICR guide and into the frame (11C).
10
11A
11B
11C
