Supplementary Operating Instructions for Explosion Protection
3
2 Motor allocation
The following maximum torques and revolution speeds, depending on the operation as vacuum pump or
compressor, may in no case be exceeded.
VH
VH
VH
VH
VH
VH
VH
VH
VH
VH
VH
VH
VH
VH
Type
20 40 60 110 140 180 300 350 400 500 600 800 1200 1600
M
Vacuum
[Nm]
5,8 9,0 10,3 33 42 60 96 110 121 173 217 481 611 741
M
Compressor
[Nm]
10,8 20,2 19,8 68 74 83
n
max
[min
-1
] 3600 3600 3600 1800 1800 1800 1800 1800 1800 1800 1800 1200 1200 1200
VU
VU
VU
VU
VU
VU
VU
VU
VU
VU
VU
VU
Type
20 40 80 140 220 300 450 500 600 800 1200 1600
M
Vacuum
[Nm]
4,9 7,5 13 40 59 82 114 151 192 364 494 650
M
Compressor
[Nm]
6,7 11,7 22 74 157 227 288 375 728 962 1183
n
max
[min
-1
] 3600 3600 3600 1800 1800 1800 1800 1800 1800 1200 1200 1200
VZ
VZ
VZ
VZ
VZ
VN
VN
VN
Type
30
50
110
140
180
95
125
180
M
Vacuum
[Nm]
6,7 10 33 42 60 33 42 60
M
Compressor
[Nm]
68 74 83
n
max
[min
-1
] 3600 3600 1800 1800 1800 1800 1800 1800
VI VI VI VI VI V V/VG V/VG V/VG V/VG V/VG V V Type
2 8 15 30 55 6 30 55 95 130 255 330 430
M
Vacuum
[Nm]
0,5 1,8 2,5 5 10 33 42 60 33 42 60 0,5 1,8
C
ompressor
[Nm]
n
max
[min
-1
]
1800 3600 3600 3600 3600
1800 1800 1800
1800 1800 1800 1800 3600
See data sheet for further operating data.
The power input designated in the process-specific data sheet for the motor to be used as well as the adjustment of
the protective motor switch is significant. The motor current is to be limited so that the power input is maximally 15%
above that of the data sheet.
3 Temperature limits
With knowledge of the temperature class, the surface temperature of the compressor may exceed the
maximum allowable temperatures in the following table in no operating condition according to EN 13463-
1.
EN 13463-1 Surface temperatures (EN 13463-1)
Temperature class Limit values maximum allowable
for category 1
maximum allowable
for category 2
T 4 135 °C 108 °C 130 °C
T 3 200 °C 160 °C 195 °C
T 2 300 °C 240 °C 290 °C
T 1 450 °C 360 °C 440 °C
If the reference basis for the identification is a certain material, then the surface temperature for
compressors of
Category 1 may reach maximally 80% of the ignition temperature in °C
Category 2 - with ignition temperatures  200°C may reach values at least 5U
- with ignition temperatures > 200°C may reach values at least 10U
below the ignition temperature
