1 Physical Specifications
1.1 Components
Note:
The following figure is for reference only, which is used to indicate the components and the
functions.
Refer to the following figure for component structure. See Figure 1-1.
Figure 1-1 Component structure
Please refer to the following table for detailed information.
Port Port Name Note
Port 1 Ethernet port Network data in/out and PoE
Port 2 DC power jack Connect to DC 12V power, input power
