To modify the SIP settings from the web based Administration Page:
1. Click Configuration, and then click SIP.
2. Modify the settings below.
Field Setting
SIP Configuration - General
Transport UDP or TCP
Default domain For a standalone CUCM enter the IP address of the
Cisco Unified Communications Manager. For a CUCM
cluster or if a SRST router is present enter the Cluster
Fully Qualified Domain Name (to be found in CUCM by
navigating to Cisco Unified CM Administration >
System > Enterprise Parameters).
Register each endpoint on sep-
arate port
Enable
Send all messages to current
registrar
Enable
Note: Only relevant if more proxies are available.
Allow internal routing fallback Must be enabled if Secondary username is defined.
For more information, see "Adding Users and Hand-
sets" on page15.
SIP Configuration - Proxies
Proxies If the Cluster Fully Qualified Domain Name is entered
in the Default domain field, fill in the IP addresses or
hostnames of the servers in prioritized order.
SIP Configuration - DTMF signalling
Send as RTP Ensure that this feature is enabled to make DTMF
tones work.
Offered RFC2833 payload type Value must be set to 101.
Note:
In order for the Spectralink IP-DECT/DECT/Virtual IP-DECT Server to support
Cisco Unified Survivable Remote Site Telephony (SRST) within a CUCM setup
with a SRST router, this feature must be configured in the CUCM. For more inform-
ation, see Cisco documentation.
