5-6 Chapter 5: Configuration, Data, and Status Tags
Owner’s Guide 0300199-01 Rev. D
value can also be multiplied. If you multiply two values together, the output
should remain within the maximum value of the Real type. Most M factors will
be within ±5% of 1.0000.
MFactor[x] 0 - 1×1032 FLOAT (C)
The R scale factor can be used for scaling of the output frequency. The output
frequency is divided by the R scale value. The frequency value is divided by the
R factor. R factors must be positive numbers. A negative value will cause a
configuration error.
SignalFilter[x] 0-3 INT
Designates whether channel 0 uses the analog filter:
0 = do not use analog or digital filter.
1 = use digital filter (25 kHz).
2 = use both digital (25 kHz) and analog (12 kHz) filters.
3= use digital (25 kHz), analog (12 kHz), and debounce filter (30 Hz).
NOTE
The digital and analog filters are separate entities which are combined into
the same tag on this module. The debounce filter debounces the input for
35 to 40 msec after the input transitions.
GateFilter[x] 0,1 INT
0 = No filter.
1 = Debounce filter.
The debounce filter debounces the input for 35 to 40 msec after the input
transitions.
RollOverTo[x] 0,1 BOOL (C)
Designates which value channel 0 will roll over to:
0 = zero.
1 = preset.
RollUnderTo[x] 0,1 BOOL (C)
Designates which value channel 0 will roll under to:
0 = normal (maximum value).
1 = preset.
Stoponzero[x] 0,1 BOOL (C)
Designates what channel 0 will do when it counts down to 0:
0 = roll under.
1 = stop at zero.
