Chapter 5: Configuration, Data, and Status Tags 5-7
Owner’s Guide 0300199-01 Rev. D
Stoponlimit[x] 0,1 BOOL (C)
Designates what channel 0 will do when it counts up to the count_limit:
0 = roll over.
1 = stop at the limit.
Disable[x] 0,1 BOOL
Enable the counter for channel [x]:
0 = enable.
1 = disable.
ResetCounter[x] 0,1 BOOL
Resets counter 0 and begins counting:
0 = do not reset.
1 = reset.
LoadPreset[x] 0.1 BOOL
Loads preset count value into counter [x] and begins counting:
0 = no action.
1 = load preset.
ResetFlags[x] 0,1 BOOL
Reset all flags:
0 = not reset.
1 = reset.
CounterInvert[x] 0,1 BOOL
Invert current direction of counter:
0 = Standard
1 = Inverted
ResetNewStoredFlag[x] 0,1 BOOL
Reset new stored data flag.
0 = not reset
1 = reset
ResetNewRateFlag[x] 0,1 BOOL
Reset rate data flag:
0 = not reset.
1 = reset.
