5-8 Chapter 5: Configuration, Data, and Status Tags
Owner’s Guide 0300199-01 Rev. D
The following data tags are preceded by the tag name
CTR8_Input.ChannelData[x] where x is the channel number 0-7.
CommStatus 0,65535 DINT
Displays module connection status:
0 = module is connected.
65535 = module is not connected.
Count[x] 0-16777215 FLOAT
Displays the channel count value.
StoredValue[x] 0-16777215 FLOAT
Displays the value of the stored counts register. The maximum value is 1677215
when scaling is off. When scaling is applied the maximum value is
1677215/K*M.
Rate[x] 0-65,000 REAL
Current rate value.
EnableEcho[x] 0,1 BOOL
Software enabled for the channel. This is an echo of the output tag:
0=Enable.
1=Disable.
WasReset[x] 0,1 BOOL
Displays whether the channel counter was reset:
0 = Counter was not reset.
1 = Counter was reset.
WasPreset[x] 0,1 BOOL
Displays whether the preset value for the channel counter was loaded:
0 = Preset value was not loaded.
1 = Preset value was loaded.
NewStoredData 0,1 BOOL
0 = Data not stored.
1 = Data stored.
NewRateData 0,1 BOOL
0 = Data is old.
1 = Data is new.
