1.2 Key Items on the XDS560v2 STM JTAG Emulator
Figure 1-1 shows the XDS560v2 STM. The key items identified are:
• Status LEDs
• JTAG Header
• Emulator Tail Assembly
• USB connector to the host PC or hub
• Ethernet connector to the host PC or router
• Power connector to power supply
Figure 1-1, KEY ITEMS ON THE XDS560v2 STM
USB Cable
Ethernet Cable
Power Supply
Power Cords
Emulator Tail
Status LEDs
USB, Ethernet,
Power Connectors
Assembly
