1 39053900 6.5 HP Speeco Engine 1
2 O/L M9 x 1,25 x 29MM Bolt 4
3 40085400 Pump Mount 1
4 O/L M7x 20 Allen Screw 4
5 39071600 Pump 1
6 39039200 3/8” NPT to 3/4” 90° Elbow 1
7 40085500 Coupler 1
8 40034800 Engine Key 1
9 39027700 Pressure Hose 1
Illustration 3
Reference Part No. Description Quantity
No.
1
2
3
4
9
5
6
7
8
Engine/Pump Assembly
NOTE: Some of the 40151000 log splitters are equipped with the pump shown below.
Please make a visual identification of your pump before ordering replacement parts or
calling for service.
Page 13
