Firmware upgrade and APP connection
Firmware upgrade
SpeedyBee F405 WING APP not supporting wireless firmware flashing, please update the firmware on a
computer. Follow these steps:
1. Press and hold the BOOT button , and connect the FC to the computer via USB cable.
2. Open the INAV Configurator on your computer, go to the “Firmware Flasher ” page, select the light controller
target as “SPEEDYBEEF405WING”, and then flash the firmware.
3. To flash Ardupilot firmware, follow the same steps as above, select “Load Firmware [local]”, and then flash the
firmware.
APP connection
Connecting Ardupilot firmware to QGroundControl app.
Check the color of the wireless status indicator. If it’s not flashing white, press the BOOT button for 6 seconds to
switch to white. Then connect to the “Speedybee F405Wing” Wi-Fi and open QGroundControl, it will automatically
connect.
