SpeedyBee F405 WING APP - Assembly Instructions

Product Name: Quick Start Guide TOPBoard FC Board
Part 1 – Overview: PDB Board, USB extender, Wireless configuration, LED strip controller, Battery level
indicator
Part 2 – Hardware Description: Digital VTX solder pads, MicroSD card slot, Telemetry module solder pads,
SBUS input pin header, GPS module solder pads, Analog VTX connector, Analog camera connector, Airspeed
sensor solder pads, ELRS receiver pin header, UART6 solder pads, Motor and servo output pin header
Supported Firmware: INAV / Ardupilot
Power Input: 2-6S LiPo
Dimension: 52cL x 32cW x 19cH mm
Weight: 35g with USB extender
Wireless Configuration: Supported
LED Strip Controller: Supported
Battery Level Indicator: Supported
Product Name SpeedyBee F405 WING APP
TOP Board SpeedyBee F405 WING Wireless Board
FC Board SpeedyBee F405 WING FC Board
PDB Board SpeedyBee F405 WING PDB Board
USB extender SpeedyBee F405 WING USB extender
Wireless configuration
Supported
LED strip controller Supported
Battery level indicator Supported
FC Firmware INAV / Ardupilot
Power Input 2-6S LiPo
Dimension 52L x 32W x 19H mm
Weight 35gwith USB extender
Assembly Instructions
