SpeedyBee F7 V3 BL32 50A 30x30 Stack - Page 8

Method 2 - All connectors
To recognize the wires in the package better, we marked some of
these wires with letters(from A to F). Please nd the right wires
accroding to their letters.
Crossre Nano Rx
CH2 RX CH1 TX 5V GND
Analog VTX DJI FPV Air Unit
V IRC G 5V
LED
GPS
FPV Cam
D
E
F
C
C
D
T
R
G
V
Cable A(3cm) or B(6cm)
