ESC power cable soldering and
recommended length for cable of motor
0 10 20 30 40 50 60 70 80 90 100 110 120 130 140
1�1 Scale
Inner motor wire recommended
length: 110mm
外走线推荐电机线长为93mm
Outer motor wire recommended
length: 93mm
*Note: connect buzzer with mark to BZ+
of ight controller, and buzzer without
mark to BZ-
ESC ESC
