Spektrum AR637T User Manual

EN
5
Using an AS3X SAFE receiver requires an approved Spektrum
™
DSM2
®
/DSMX
®
compatible transmitter.
Transmitter and receiver binding
Binding
The AR637T receiver must be bound to the transmitter before it will operate.
Binding is the process of teaching the receiver the specifi c code of the
transmitter so it will only connect to that specifi c transmitter. When new out of
the package, the AR637T will automatically go into bind mode the fi rst time it
is powered on.
1. Connect the optional SRXL2 remote receiver (9747) if desired and any
telemetry sensors to the main receiver.
2. Push and hold the bind button on the receiver while turning the receiver on.
Release the bind button once the orange LED starts to fl ash continuously,
indicating that the receiver is in bind mode.
Tip: It is still possible to use a bind plug in the BIND port if desired. This
can come in handy if the receiver needs to be mounted in a location that is
diffi cult to access, in which case a servo extension may be used for binding.
3. Put your transmitter in bind mode.
4. The bind process is complete when the orange LED on the receiver is solid.
NOTICE: If using a bind plug, remove after binding to prevent the system
from entering bind mode the next time the power is turned on.
5. After you set up your model, always rebind the transmitter and receiver to
set the desired failsafe positions. See FAILSAFE on the next page.

Spektrum AR637T Specifications

General

Quantity per pack	1 pc(s)
Voltage	9 V
Type	Radio-Controlled (RC) Model Parts
Modulation	DSM2, DSMX
Product type	Receiver
Product color	Multicolor
Antenna length	186 mm
Channels quantity	6 channels
Brand compatibility	Spektrum

Weight and Dimensions

Depth	49.8 mm
Width	23.34 mm
Height	15.02 mm
Weight	12 g
