Spektrum AS3000 User Manual

EN
4
Bind the PowerSafe Receiver
1. Bind the Forward Programming enabled PowerSafe Receiver to a Forward
Programming enabled transmitter. See the receiver manual for binding
instructions.
2. Fly and trim the aircraft before proceeding.
Installing the AS3000 AS3X Flight Stabilization Module
IMPORTANT: Update your Spektrum transmitter with the latest Spektrum
AirWare
™
software to take advantage of Forward Programming.
See the transmitter manual for updating instructions.
1 3
5 7
42
6 8
IMPORTANT: Do not
mount the sensor
perpendicular to the
 ight path.
Installation
1. Solidly mount the AS3000 on a smooth  at surface in the aircraft. The
module must be mounted  at and in line with the nose/tail. There are
8orientation options available.
2. Connect the cable from the Sensor port on the receiver to the port on the
rear of the AS3000.
