12 SPEKTRUM DX3R PROGRAMMING GUIDE
12. Connect the steering wheel mechanism connector
to the connector from the transmitter being sure
the connection is tight. Note correct polarity.
13. Fit the other handed backplate in place and
secure the steering wheel assembly in place
using the three long cap head screws.
14. Fit the grip in place and reinstall the batteries.
Note that the buttons D and E now work in
reverse. It will be necessary to change the
direction of these switches in the System menu
(see page 29)
usIng The rollIng seleCTor
The Rolling Selector is pressed to access functions
and rolled to selected specific features or to change
setting or values. Pressing and holding the rolling
selector for more that 3 seconds returns the display
to the main screen.
The DX3R features one-touch programming
utilizing a Rolling Selector. The Rolling Selector
has three functions:
1: Pressing the Rolling Selector - enters the
selected function
2: Rolling the Rolling Selector - highlights function or
changes settings and values when selected.
3: Pressing and holding the rolling selector for more
than 3 seconds from any screen - returns the display
to the Main Screen.
Programming is very intuitive and always starts
with a press, then a roll, then a press, roll and
so on. Most find that within a few minutes they’re
able to easily program their car without reading
the instructions, however, to realize the full benefit
of the programming it’s recommended that the
manual be read.
Most racers find it’s most convenient to use their
thumb when making programming changes, as
this allows for one-handed programming, even
allowing the car to be run in one hand while making
programming adjustments in the other.
Note: Each individual page from this point
is dedicated to a single specific programming
function.
