18 SPEKTRUM DX3R PROGRAMMING GUIDE
sTeerIng raTe
01: Model 01
St ee r Ra te
User Name
S/R
100%
S/R Override
INHIBIT
≤
Steering rate (also know as dual rate) allows on-
the-fly steering travel adjustments to be made using
any of the programmable grip trimmers (A,B,C,D, or
E). The Steering Rate screen also offers a Steering
override function that allows a second steering rate
(normally 100%) to be accessed at the touch of
a button or trimmer. This is especially helpful for
oval racers that program minimal steering throw
to desensitize steering during racing but require
maximum steering angle to drive out of a crash or
get turned around on the track. The user name and
model number and model name are also displayed
in this screen.
To aCCess The
sTeerIng raTe funCTIon:
In the List screen use the roller to highlight the
Steering Rate function.
Press the roller to access the Steering Rate function.
The above screen will appear.
Use the roller to select the S/R function or the S/R
Override function by placing the box around the
desired function.
Press the roller to access S/R or S/R Override;
then use the roller to change to the desired
Steering rate value.
To return to the main screen press and hold the
roller for more than three seconds.
Note: An adjustable S/R rate can be assigned
to any of the trimmers (A,B,C,D and E) and is
defaulted to trimmer D. This trimmer works in
unison with the S/R Rate screen and the value
can be adjusted from either the screen or from
the programmable trimmer. If it’s desired to
not have an on-the-fly adjustable Steering Rate
the S/R trimmer can be inhibited. See System
function under switch selection on page 29 for
more details.
Note: In order for the S/R Override to operate
it must be assigned to a switch or trimmer. The
default position for this function is inhibited.
To activate the S/R rate, it’s necessary to
program this function to the desired switch or
trimmer in the System function screen under
Switch. See page 29.
