12
COMPOSITE AV CONNECTION
YPbPr CONNECTION
AV cable
(Optional)
For basic connection, use the
composite Audio L/R (white/red)
and CVBS cable to connect the
unit with other devices.
Back of DVD/VCR
Back of DVD/VCR
YPbPr cable
(Optional)
Audio cable
(Optional)
