3.0
UNPACKING
Carefully inspect the exterior of the packing box. Any visible damage should immediately be
reported to the carrier. Remove all packing documents from the exterior of the box, and file in
your records. Open the top of the shipping box. Remove the foamed-in-place packing material by
lifting on the retaining plastic sheet. Remove the accessory pack and place nearby. Grasp the mill
on both sides, and gently remove from the packing box. Place the mill on the benchtop where the
mill is to stay. Visually check the machine for any hidden damage that may have occurred during
shipping. Unlatch the lid, and inspect the interior of the tub, ensuring that it is free of any
packing debris or visible damage. Raise and lower the lid to insure that the coil gate (handle with
roller) is moving freely and properly.
Each new 6750 Freezer/Mill comes with a 6754 Extractor (page 21) and a 6755 Vial Rack.
Grinding vials are necessary for processing samples but must be purchased separately. The 6751
Vial, the 6752 Steel Center Section, and the 6753 Microvial set are described on pages 20-21.
The 6814 Auto-Extractor (page 29) is an optional accessory for mechanized removal of end
plugs.
Inspect the accessory pack. Remove the Packing List and use it to check that there are no parts
missing. If everything seems to be in proper order, then store the packaging materials, in case
there is a need to return the unit for future service or repair.
Control Panel Lid Assembly
Electrical Inlet
Module at back
On/Off Button at
back
6750 Freezer/Mill
