SPEX 6750 - Parts List & Item Locator

To Next Page

To Previous Page

8.0

PARTS LIST & ITEM LOCATOR

(see Diagrams A, B, & C)

Item

Part No. Description

Location

(Diagram, Page #)

1 50587 Latch A, 24

2 38550 Tub, Outer A, 24

3 39079 Foam, Top Plate A, 24

4 92679 Switch, Pushbutton A, 24

5 38569 Driver Board A, 24

6 38579 Power Supply A, 24

7 96004 AC Inlet A, 24

8 96005 Fuse Holder A, 24

9 93850 Fuse, 8 Amp for 115V (2 required) A, 24

10 93840 Fuse, 5 Amp for 230V (2 required) A, 24

11 39080 Foam, Back-plate A, 24

12 92703 Power Switch A, 24

13 38567 Gas Spring for Lid A, 24

14 92710 Switch, Magnetic A, 24

15 92711 Actuator, Magnetic A, 24

16 50588 Hinge B, 25

17 38531 Top Cover B, 25

18 38562 Processor Board B, 25

19 38549 Control Panel Overlay B, 25

20 39043 Foam, Sealing Plate B, 25

21 24456 Tub, Inner B, 25

22 31522 Collar B, 25

23 38560 Tub Insulation B, 25

24 93725 Rubber Foot (4 Required) B, 25

25 24445 Anvil C, 26

26 50541 Retaining Ring C, 26

27 32350 Rod C, 26

28 38853 Liquid Level Sensor C, 26

29 38539 Pivot Pin Yoke C, 26

30 38548R Coil (Solenoid) Assembly, 115V/230V C, 26

NOTE: Please refer to pages 20 and 21 for vial accessory parts.

Page 22 of 28
