Sphere PWM Series User Manual

LED
Display
Mode
LED
Display
Mode
0
Pure light control mode
9
Light control + time
control (9 hours)
1
Light control + time
control (1 hour)
10
Light control + time
control (10 hours)
2
Light control + time
control (2 hours)
11
Light control + time
control (11 hours)
3
Light control + time
control (3 hours)
12
Light control + time
control (12 hours)
4
Light control + time
control (4 hours)
13
Light control + time
control (13 hours)
5
Light control + time
control (5 hours)
14
Light control + time
control (14 hours)
6
Light control + time
control (6 hours)
15
Manual mode (default)
7
Light control + time
control (7 hours)
16
Debugging mode
8
Light control + time
control (8 hours)
17
Normal on mode
5. Load Working Mode Settings
In the load mode menu, long press for 2s, and the number (e.g. 15) will begin to flash. Press to adjust the mode (from 0 to 17), and
then long press again for 2s to complete and save the setting.
Note: 1. After parameter adjustment, if is not pressed and held long enough for exiting , the system exits to the main menu after 12s, and the
parameter that was set is not saved.
2. When the system is saving data, the screen may shake slightly. This is normal and the user may ignore it.
6. Safety Advice
1) When connected to a 24 V or 48V system, the solar panel terminal voltage may exceed the limit for human safety. If operation is to be
performed, be sure to use insulation tools and keep your hands dry.
2) If the battery is reversely connected, the controller itself won't be damaged, but the load end will have a negative voltage output, which may
damage your load device. Take care not to let this happen.
