SPHINX Project Twelve - Rear Panel

SPHINX Project Twelve
5
Rear panel
1. BALANCED/UNBALANCED: With this switch
you may select the input (4.) to balanced
(switch IN) or unbalanced.
2. CONTROL IN: To connect the optical cable
from another Sphinx component like a pre-amp.
CONTROL OUT: To connect the optical cable
that goes to another Sphinx component.
3. XLR input: To connect the XLR cable from the
pre-amp output.
4. POWER: This is the mains master switch.
MAINS: To connect the power amp to a mains
outlet (230 - 240 VAC).
5. OUTPUT: To connect the cable from the
loudspeaker:
red +
white -
6. Cinch: To connect the cinch cable from the pre-
amp output.
