ONDERDELENLIJST
Pos
nr.
Omschrijving
Aantal
Maat
1
Inbusbout
2
M5x14
2
Kentekenplaathouder
1
3
Kentekenplaathouder
bevestigingsbeugel
1
4
Achterlicht links
1
5
Kunststof lampbeschermer links
1
6
Kunststof wielstopper
4
7
Rubber velgbeschermer
4
8
Aluminium wielhouder basis links
1
9
Kunststof afdekkap
1
10
Bout
1
M10x115
11
Sluitring
14
M10
12
Aluminium framehouder
2
13
Zelfborgende moer
7
M10
14
Kunststof afdekkap
1
15
Kunststof interieur voor scharnier
2
16
Basisframe met snelkoppeling*
1
17
Kunststof kapje*
4
18
Schroef
5
St4.8x20
19
Aluminium wielhouder basis rechts
1
20
Kunststof lampbeschermer rechts
1
21
Achterlicht rechts
1
22
Basisframe met snelkoppeling
(Xplorer)/kantelframe (Xplorer
+
)
1
23
Kunststof voetje lang
2
24
Boutje
2
M5x40
25
Kantelmechanisme pedaal*
1
26
Sluitring
2
M5
27
Bout
4
M10x100
28
Sluitring
2
M5
29
Zelfborgende moer
2
M5
30
Sluitring
10
M5
31
Kentekenplaat vergrendeling
1
32
Kunststof afdekkapje
2
33
Kunststof voetje kort
2
34
Boutje
2
M5x20
35
Kunststof ring
8
36
Boutje
1
M5x16
37
Bout*
2
M10x80
38
Kentekenplaat scharnierbeugeltje
1
* Alleen van toepassing voor de Spinder Xplorer
+
(incl. kantelmechanisme)
