Spinder XPLORER - Spare Parts Overview (Table)

65
PART LIST
Pos
nr.
Description
QTY
Remark
1
Inner-socket bolt
2
M5x14
2
License plate holder
1
3
License plate holder bracket
1
4
Rearlight left
1
5
Lamp protector (left)
1
6
Plastic wheelstopper
4
7
Rubber rimprotector
4
8
Aluminium wheelholder frame left
1
9
Plastic cover
1
10
Bolt
1
M10x115
11
Washer
14
M10
12
Aluminium Frameholder
2
13
Nylon nut
7
M10
14
Plastic cover
1
15
Plastic interier for hinge
2
16
Mainframe with quick connector*
1
17
Plastic cover*
4
18
Screw
5
St4.8x20
19
Aluminium wheelholder frame
right
1
20
Lamp protector (right)
1
21
Rearlight right
1
22
Mainframe with quick connector
(Xplorer) / Tilting frame (Xplorer
+
)
1
23
Plastic support (long)
2
24
Bolt
2
M5x40
25
Tiltingpedal*
1
26
Washer
2
M5
27
Bolt
4
M10x100
28
Washer
4
M5
29
Nylon nut
2
M5
30
Washer
10
M5
31
License plate holder locking
1
32
Plastic cover
2
33
Plastic support (short)
2
34
Bolt
2
M5x20
35
Plastic washer
8
36
Bolt
1
M5x16
37
Bolt*
2
M10x80
38
License plate holder hinge
1
* Only applicable for the de Spinder Xplorer
+
