ZS-LC/5 & ZS-LC/10 Load Display ZS-LC/5 & ZS-LC/10 Load Display
ZS-LC/5 & ZS-LC/10
ZS-LC/5 & ZS-LC/10
Power Button
• Turn the cell ON by holding down the power button until the screen
comes on. The cell will read load instantly and does not need to be
‘unloaded’ when turned on.
• The load reading will update continuously until 6 minutes has passed
when the unit will automatically power down.
• To turn OFF manually press and hold until the screen goes past ‘Zer’ to
OFF then release the button.
Page Button
• Use this button to switch between TRACKING, PEAK and PEAK
READING modes.
• To enter PEAK press and hold down the page button until the screen
ashed between P and a reading.
• In PEAK mode the unit will remain ON until the battery runs out unless
turned OFF.
• To read the PEAK load hold down the page button until PPP ashes
intermittently with the reading.
• Return to TRACKING mode by holding down the page button. This
resets the PEAK READING to zero.
• BASIC INSTRUCTIONS ARE SHOWN ON THE BATTERY COVER
Zeroing
• From time to time it may be necessary to ZERO the reading due to
climatic conditions. To ZERO press and hold the POWER button and
release when ‘Zer’ appears on screen.
Overload
• If the screen ashes OL in any mode the unit has experienced a
signicant overload and will require re-calibration.
• OVERLOADING 200% OF SWL WILL RESULT IN PERMANENT
DAMAGE TO LOAD CELL
• A calibration certicate is available and valid for 12 months. The unit
must be returned to Spinlock for re-calibration.
Battery Life
• The PP3 9v battery supplied with the unit will last between 2 and 6
hours depending on the range of load measured.
• When the battery power is low the decimal place will start to ash.
• VERY LOW VOLTAGE BATTERIES MAY GIVE INACCURATE
READINGS.
• STORAGE WITH BATTERY CAN RESULT IN LEAKAGE AND
DAMAGE.
Battery Replacement
• To change the battery carefully unscrew the 3 at blade stainless steel
screws with an appropriate sized screw driver.
• Lift of the plastic battery cover and place down without disturbing the seal
• Lift out and detach the battery without straining the wires.
• Clip on a new PP3 9v battery and place inside the compartment with the
battery terminal at the same end as the wire exits the load cell body.
• Replace the plastic battery cover and carefully locate the 3 bolts before
screwing evenly until the seal is compressed an even amount all round.
• DO NOT OVER TIGHTEN THE SCREWS
