SPINNING® STUDIO CONSOLE OWNERS MANUAL
21
Attach the Console to the Bike
To attach the console to the bike:
1. Place the rubber gasket inlay behind the
console (Figure 10).
2. Select the flat bracket and secure it to the
back of the console with the three screws
(Figure 11).
Note Older bike models may require a
dierent console mounting bracket.
Choose the one appropriate for your bike.
3. Mount the console and bracket assembly
just above the handlebars using four screws
and four spacers. See Figure 13 for newer bike
models and Figure 14 for older bike models.
Figure 10
Figure 11
Figure 12
Before attaching your Spinning® Studio Console to your Spinner® bike, make
sure that the console is pairing properly with your cadence sensor and heart
rate transmitter.
Figure 14Figure 13
