IM-P006-07 CTLS Issue 12
8
2.2 DP163, DP163G and DP163H
2.2.1 Description
The DP163, DP163G and DP163Y pilot operated
pressure reducing valves have been manufactured
using stainless steel.
Available types
DP163 Suitable for steam applications
DP163G Is a soft seal version available for compressed
air and inert industrial gases.
Note: It is not recommended for oxygen
service.
DP163Y Having a lower rate pressure control spring is
suitable for steriliser/autoclave applications
2.2.2 Sizes and pipe connections
DN15LC - Low Capacity version, DN15, DN20, DN25, DN32, DN40, DN50 and DN80.
Standard flanges: EN 1092 PN25 and PN40, BS 10 Table 'J' and ASME 300.
Available on request: ASME 150 and JIS 20.
